Triple Glazing Low-E Vacuum Insulated Glass Rducing Noise For Windows and Doors
Product Description of Insulated Glass:
Insulating glass is made of two pieces or more pieces of tempered glass, which is spaced out a certain width of space with the internal high efficiency molecular sieve absorbent aluminum frame and bonded with the high strength sealant in the edge. The sealed air inside the insulating glass, under the action of the high efficient molecular sieve adsorbent filled with aluminum frame, creates the dry air with low thermal conductivity, thus forms a heat and noise insulation barrier. If the inert gas is filled in the space, it can further improve the insulation and sound insulation performance of the product. In particular, insulating glass products made by the low-E coating (lower-E) glass can enhance the performance of heat preservation and thermal insulation of building doors and windows and curtain walls. Insulating glass usually has two product structures of single cavity and two-chamber.
Feature of Insulated Glass:
1. Large Energy Saving Effect: High-performance insluating glass, due to a special metal film, can reach 0.22-0.49 shielding coefficient, so that the load of indoor air conditioning (cooling) is reduced. The heat transfer coefficient is 1.4-2.8W (m2.K), which is better than ordinary insulating glass. It also plays a great role in reducing indoor heating load. Therefore, the larger the window is opened, the more obvious the energy saving effect.
2. Improve indoor environment: High-performance insulating glass can intercept the considerable energy hit by the sun indoors, thus preventing the discomfort caused by radiant heat and reducing the dazzling caused by the evening sunlight.
3. High transmittance: visible light transmittance near 92%, 6% higher than clear float glass.
4. High Safety: When the glass is damaged by external force, the fragments will be broken into small particles like honeycomb-shaped obtuse angle, which is not easy to cause serious harm to the human body.
Application of Insulated Glass:
1. Electronic Displays
2. Cover Screens – monitor face plates
3. LCD Displays
4. Computer Screens
5. Projection Monitors
6. Advertising Panels – outdoor electronic monitors & systems
7. Touch Screens
8. Medical Instrumentation
9. Ruggedized Displays
| What is Low-E insulated glass |
| Structure | Double wall / Triple wall with Aluminum spacer (Connected by Structure sealant) |
| Raw glass thickness | 3mm,4mm,5mm,6mm,8mm,10mm,15mm,19mm |
| Color | Blue, Green, Brown, Grey, tea color, etc. |
| Advantages | 1) Heat isolation and warmth preservation 2) Distinct energy-saving effect, decreasing air-conditioning and heating costs 3) Good soundproofing performance makes rooms comfortable 4) Good anti-frosting and dew-formation properties 5) IR reflected |
| Standard insulated glass thickness (Glass + Aluminum spacer + Glass) / mm |
| Item | Glass thick | Product parameter(mm) |
| Double/triple wall insulated glass | 4mm | 4+4A+4 | 4+5A+4 | 4+6A+4 |
| 5mm | 5+6A+5 | 5+7A+5 | 5+8A+5 |
| 6mm | 6+6A+6 | 6+7A+6 | 6+8A+6 |
| 8mm | 8+6A+8 | 8+7A+8 | 8+8A+8 |
| 10mm | 10+6A+10 | 10+9A+10 | 10+12A+10 |
| 12mm | 12+9A+12 | 12+12A+12 | 12+16A+12 |
| Aluminum spacer thickness | 4mm, 5mm, 5.5mm, 6mm, 6.5mm, 7mm, 8mm, 8.5mm, 9mm, 10mm, 11mm, 11.5mm, 12mm, 14mm, 14.5mm, 15mm, 16mm, 17mm, etc. |
| Remark | For other thickness, produce according to customer's requirements |
Packaging & Delivery:
Standard export package: Plywood or wooden crate
Corner protector and protective film is available
Crates shall be banded by steel bands
Why choose us:
- Competitive price, value for money
- Expertise on glass & mirror products
- Prompt communication & service
- Quality products
- On Time Delivery
- Flexible on order qty & consolidation
